Indeed more healthy air for your infant
Infants and young children breath almost two times faster than adults. Air pollution as we all know is very harmful to adults' health, but babies and children's health is our greater concern.
Tipon TIFA01 Series, purifies the inlet air gradually through different filters, assures you healthy air and let your baby grow up in a healthy air environment.
Enjoy the clean air....Tipon
Filters out PM2.5: 99.64% (run in 30 m³ box in 110 minutes)
Filters out formaldehyde: 95.00% (run in 30m³ box in 300 minutes)
Data source: China Testing & Inspection Institute of Household Electric Appliances
Tipon german headquarter: Tipon (Germany) Environmental Technology GmbH
Address: Lilienhof, Lilienstrasse 11, hamburg, Germany
Tipon china headquarter: Tipon (Zhuhai) Environmental Technology Co., Ltd
Address: Yong'an Road, Liangang Industrial Zone, Jinwan district, Zhuhai, Guangdong Province, P.R.China.
Tel: 0086-756-6297020 Fax: 0086-756-6297021
Tipon china factory: Zhuhai Zhengyou Technology Co., Ltd
Address: Yong'an Road, Liangang Industrial Zone, Jinwan district, Zhuhai, Guangdong Province, P.R.China.
Tel: 0086-756-6297000
TIFA01 Highlights
lovely shape, special for babies
ventilation function, suck in the fresh air from outside, provides enough fresh air
anion increases oxygen amount
activated carbon remove odors, filters out formaldehyde, benzene and other harmful substances.
Medical HEPA Filter effectively filters out PM2.5
odors, pollen and dust detector
4-step light indicators clearly show air quality level/ Smart air auto detecting
indoor & outdoor air bicirculating purification
Timer (2/4/8h)
light indicator for filter replacement
Wall-mounted installation
Structural Features
TIFA01 wall-mounted air purifier, sucking the outdoor air and indoor air through the air inlet of the air purifer, the air goes through all filters and the built-in ionizer device, after that the purified air comes out, the process repeats again and again. After few times circulation, the amount of dust, pollen, germs and part of the harmful gases in the air will be dramatically reduced, thus assures you healthy air always.
4 different filters 8-stage filtration
Tipon uses incrementally filtration technology, effectively filters out dust, germs,virus, formaldehyde, odors, harmful gases and other hazardous substances.
Pre-filter
is made from polyester and premium PP material, light, easy to install, washable and cost-saving, it can filter out big particles and hair.
EVA Filter
is porous spongy mesh, made from EVA foam material, can seperate big particles and water macromolecules, thus extends lifetime of the filters.
Second filter
is made of medical non-woven fabrics, effectively filters out hair and big particles; with special added anti-allergic and anti-bacterial formula
can effectively prevent babies and the elders from respiratory infection and viral influenza.
Activated carbon filter
Honeycomb-like activated carbon filter, with added premium coconut shell charcoal in the plastic honeycomb mesh and being wrapped with polyester cloth, absorbs effectively organic compounds, formaldehyde, toluene, hydrogen sulphide, chlorobezene and other suspended particles in the air.
|
HEPA Filter
is made of medical non-wolven fabrics, has high efficiency and low resistance, can effectivly filter out suspended particles (0.3μm).
Ionizer
Ionizer is also called negative ion generator. Negative ions are dispelled into the room where they attach to dust, pollen, cigarette smoke and pet dander to form larger particles, which can more easily be trapped by air purifier 's filters. Ionizer helps you to breathe better.
Total heat recovery concept
In winter the indoor air is heated up
cold fresh air from outside
warm stale air from inside
indoor air temperature after exchange: (indoor temperature-outdoor temperature) x heat exchange rate + outdoor temperature
Example: （20°C - 0°C）x 70% + 0°C =14°C
In summer the indoor air is cooled down
warm fresh air from outside
cold stale air from inside
indoor air temperature after exchange: indoor temperature - (indoor temperature-outdoor temperature) x heat exchange rate
Example: 32°C - (32°C - 26°C) x 70% =27.8°C
Air convection proportion regulation system, invented by tipon germany, according to the indoor outdoor temperature differences it can adjust the proportion of cold warm air exchange.
Total indoor air purification is suggested when outdoor air is heavily polluted.
Balanced inlet air purification is suggested when air ventilation in the room is neccesary. For example: when children, elders or someone suffers from respiratory diseases.
Total outdoor air purification is suggested when outdoor air quality is clearly better than indoor air.
Core technology
Environment-friendly filtration technology: removes harmful substances, like pollen, dust, germs, virus, formaldehyde, odors and other hazardous gases.
Smart control, always safe:
Tipon smart air detection system checks instantly the indoor air quality, and with the help of inteligent fresh air system we assure you an personal, healthy and safety living environment with clean air.
24 hours fresh air circulation:
high efficient smart exchange system, varies exchangement modes, high air volume , thorough and effiecient, assures fresh air round the clock.
Ultrasilent: thanks the advanced technology for ultrasilent operation, non disturbance to your work and rest.
Anion gives you refreshed strolling feelings like in forests: If we breathe in anions, it promotes our cells' metabolism and increases vitality, cleans blood and is effective for stability of nerves and exhaustion recovery. (Therefore, an anion is even called the vitamin of the air.)
Ionizer's working principle diagram
The Anions can let PM2.5 and other particulates, which are invisible by human eyes, form into molecules and descend to the floor by making negativ and positiv ions attach or collid with each other. And Anions reverse the bipoliarity of the bacterial proteins, thus they reduce the viability of germs or kill them .
The special feature of Ionizer is its rapid inactivation and high inactivation, it can also inactivate the microorganisms, germs and virus in the air and on surfaces.
|
